Cartridge FILTER HOUSINGS



Cartridge Filter Housings

Cartridge filter housings are manufactured from polypropylene, polyethylene, or PVDF, depending on the application, temperature, and medium. They are available in various lengths and can accommodate up to 120 filter cartridges. Special customer requirements can be accommodated. The filter housings are compatible with a variety of filter adaptors, including DOE, C2, C3, C7, and C8.

Advantages:

  • Different kind of plastics for practical all applications
  • Postion of inlet and/or outlet can be changed
  • Standard operating pressure 6 and 10 bar.
  • In accordance with the PED standards
  • Can be CE marked

Technical details:

Material PP, PE, PVDF
O-ring FTP, EPDM, PTFE coated
Cartridge length 10" to 60"
number of cartridges 1 to 120 pcs
Adaptor DOE, C0, C2, C3, C7, C8
Connections Flens ANSI/DIN, BSP/NPT (M/F)
Pressure at 40ºC* 6 or 10 bar
Max. temperature* PP 60ºC
PE 50ºC
PVDF 90ºC
* Chemical weakening if any not taken into account
